Denon AVR-X3800H 9.4 Channel 8K Home Theater Receiver

Powering 105W per channel the Denon AVR-X3800H 9.4 channel 8K AV receiver delivers an enveloping 3D audio experience and amazing picture quality thanks to Dolby Atmos® DTS:X® and the latest HDMI technology featuring HDR10+ Dolby Vision™ and 8K video. Powered by HEOS® Built-in access streaming music services and share with HEOS-enabled speakers in other rooms. With flexibility to set up the best speaker arrangement for your space and Audyssey MultEQ XT32 room correction technology to optimize the sound Denon made this AV receiver to meet the demands of home theater enthusiasts like you.
Features
Immersive sound from 9.4 channels Dolby Atmos DTS:X and IMAX Enhanced
Simple intuitive setup including Audyssey Room Correction Suite
HEOS Built-in with WiFi and Bluetooth
Configuration flexibility with 11.4 channel processing capability and Pre-Amplifer mode
Increased HDMI 2.1 Connectivity with six 8K inputs (6/3 total HDMI in/out)
New HD GUI AIOS 6.0 New Networking Platform (Module + Antenna)
Griffin Lite XP – Upgraded DSP with higher calculation power
Auro 3D processing
4 independent subwoofer pre outs
Dirac Live Upgradability
HDMI +5V output power 300mA capability for all output (incl. Zone2 output)
High Performance 9- Channel Amplifier
Discrete high-current amplifiers deliver up to 105W per channel (at 8 ohms 20- 20kHz THD 0.08%)—enough power to drive any speaker.
3D Audio Experience
Get enveloped in sound with Dolby Atmos® DTS:X® IMAX Enhanced and Auro 3D along with Dolby Surround DTS Neural:X and Auro-Matic upmixer to optimize legacy content.
Configuration Flexibility
AVR-X3800H offers many setup options and flexibility to adjust your home theater to meet your needs. Supports 11.4 channel processing capability PreAmplifier mode and optional Dirac Live upgradability (with fee coming soon in 2023).
Advanced 8K Home Theater
8K video is supported on all six HDMI inputs and two of the three outputs. Enjoy easy video compatibility and great picture quality with HLG HDR Dolby Vision HDR10+ and Dynamic HDR passthrough.
HEOS® Built-In Technology
Stream music wirelessly from a variety of free and premium streaming services. Share content to HEOS devices like Denon Home speakers in other rooms.
Audyssey Room Correction Technology
Audyssey MultEQ XT32 room correction features are built in for accurate setup and calibration to provide the most optimal listening experience for your room.
110+ Years Of Innovation
Founded in 1910 Denon enables the moments that matter through the relentless pursuit of quality innovation and audio performance.
What’s in the Box
AVR-X3800H 9.4 Channel 8K Home Theater Receiver IMAX Enhanced with Dolby Atmos/DTS:X and HEOS Built-In (Factory Certified Refurbished)
Remote Control
Batteries
AM/FM Antennas
AC Cord
Audyssey Microphone
Quick Start Guide
Specifications
Multichannel Surround
DTS HD Master DTS:X DTS:X Pro: Yes Yes No
DTS Neo:X DTS Neural:X: Yes No
DTS Virtual:X: Yes
IMAX Enhanced: Yes
Dolby TrueHD Dolby Atmos Dolby Atmos Height Virtualization Dolby Atmos Music: Yes Yes Yes Yes
Dolby ProLogic Ilz Dolby Surround: Yes No
Auro 3D: Yes
360 Reality Audio/MPEG H: Yes Yes
Multichannel Stereo: Yes
Max. Number of Processing (Pre-Amp) Channels: 11.4
Sound Enhancements
Mono Block Power Amp Construction: No
Discrete Power Amplifier: Yes
D.D.S.C. HD Digital: No
Pure Direct: Yes
Gold-Plated RCA Terminals: No
Clock Jitter Reducer: No
Alpha Processing: No
Audyssey: MultEQ XT32
Audyssey Dynamic EQ Dynamic Volume: Yes Yes
Audyssey LFC: Yes
Dirac Live Upgradability: Yes
Compressed Audio Restorer: Yes
Network
Media Server: Yes
HEOS Wireless Multi-Room Technology: Yes
Alexa/Google Voice Assistant/Apple HomePod: Yes Yes Yes
Lossy Formats: MP3 WMA AAC: Yes Yes Yes
Lossless Formats: FLAC ALAC WAV: Yes Yes Yes
Lossless Formats: FLAC HD WAV ALAC (all 192kHz/24 bit): Yes Yes Yes
DSD Audio Streaming: Yes (2.8/5.6MHz)
AirPlay 2: Yes
TuneIn: Yes
Spotify Connect: Yes
Pandora: Yes
SiriusXM: Yes
Roon Tested: Yes
HEOS App Control: Yes
Compatible with Remote APP for Smart Phones: Denon 2016 AVR Remote
Ethernet Ports: Yes
Wi-Fi: Yes
Bluetooth: Yes
HDMI
HDMI Inputs: Back Front: 6 No
HDCP2.3 Support: Yes
HDMI Outputs: Main Zone: 2 1
HDMI 2.1: 8K/60Hz AB 4K/120Hz AB: Yes Yes
HDR HLG Dolby Vision HDR10+ Dynamic HDR: Yes Yes Yes Yes Yes
ALLM (Auto Low Latency Mode) Pass-Through for Gaming: Yes
Variable Refresh Rate Quick Flame Transport Quick Media Switching: Yes Yes No
3D Signal Pass-Through: Yes
8K Signal Pass-Through Scaling GUI Overlay: Yes Yes Yes
DSD Audio Capability: Yes
Audio Return Channel (ARC) Enhanced ARC: Yes Yes
Auto LipSync: Yes
Multiroom / CI
Multi-Room Zones: 2
Zone Audio Source: HDMI;  Optical Coax  Network  USB; Analog: Yes (2ch) Yes (2ch) Yes Yes
Zone Audio Output: Speaker Pre-Out: Yes Yes
Zone HDMI Output from HDMI Source: Yes
IP Control RS232 Control Web Control App Control: Yes Yes Yes Yes
Remote In/Out: Yes Yes
DC Trigger Output: 1
HDMI Diagnostics: Yes
Others
Auto Speaker Setup by Microphone: Audyssey MultEQ XT32 Dirac Live (upgrade)
Front Display: 1-Line FLD
GUI Languages: 3
Setup Assistant: Yes
Quick Select Plus Quick Select: Yes No
Variable Crossover: Yes
Optimized Bass Redirection: Yes
Bass Sync: Yes
ECO Mode: Yes
Auto Power Off: Yes
Sleep Timer: Yes
Inputs/Outputs
Video
HDMI In Out : 6 3
Multi-Room Video Out: Video HDMI: Yes No
Audio
Analog In Out: 5 No
Phono (MM) In: Yes
Digital In: Optical Coaxial: 2 2
Multi-Room Out: Analog Digital: 1 No
Multichannel Pre-Out: Yes (11.4)
Subwoofer Out: 4 (independent)
Other
Speaker Terminal: Gold-Plated Screw Regular Screw       Yes No
Number of Speaker Terminals: 11
Speaker A/B: Assignable
Bi-Amp Drive: Assignable
Multi-Room Speaker Terminal: Assignable
Front Inputs: Audio Composite Digital (Opt) HDMI USB: No No No No Yes
USB Audio Made for iPod Made for iPhone: Yes No No
AM/FM Tuner: Yes
Power
Number of Power Amps: 9
Power Output (8 ohm 20Hz – 20kHz 0.08% 2ch Drive): 105W
Power Output (8 ohm 20Hz – 20kHz 0.05% 2ch Drive): No
Power Output (6 ohm 1kHz 0.7% 2ch Drive): 135W
Power Output (6 ohm 1kHz 10% 1ch Drive): 215W
General
Metal Front Panel: No
System Remote Control: RC-1253
Pre-Programmed Learnable LCD Display: No No No
Power Consumption in W: 660W
Power Consumption No-Sound  (ECO on/off) in W:  60W/100W
Standby Consumption in W: 0.1
CEC Standby Consumption in W: 0.5
Network Standby Consumption in W: Less than 2.0
Maximum Dimensions (W x H x D)
W/ Antenna: Horizontal: 17.1” x 6.6” x 15.3”
W/ Antenna: Vertical: 17.1” x 9.3” x 15.3”
W/o Antenna: 17.1” x 6.6” x 14.9”
Weight in lbs: 27.6
